EL61

EL61

The EL61 stationary scanner with imaging technology is ideal for use in self-service and specialty retail stores as well as department stores and other retail businesses with a high turnover of goods.

Features & Benefits

Specifications

Additional Information

Product Card

Reference Manuals, Firmware and Drivers

Diebold EL61 Stationary Scanner

Features & Benefits

Highlights

  • Compact in-counter image scanner with a small footprint and minimum weight
  • Integrated deactivation antenna to connect an electronic article surveillance (EAS) system from Checkpoint
  • Omnidirectional barcode recognition in scanning and presentation mode
  • Excellent, multicode-capable scanning performance for barcode labels that are difficult to read due to poor printing quality
  • Additional visual read confirmation
  • Supports multiple interfaces
  • RS232 or USB interface powered by the BEETLE POS system family
  • Imaging technology without moving parts improves reliability and lengthens the service life
  • Recognition of linear 1D and 2D barcodes on mobile phones and PDAs
  • Image capture and storage on microSD card or transfer to the BEETLE system
  • Configurable and programmable with traditional programming barcodes or microSD card
  • Low power consumption
  • Optional Productivity Index Reporting™ software
  • Suitable for replacing the horizontal, stationary scanner EL46

Specifications

SYSTEM VERSIONS

Horizontal, stationary Scanner

  • Multi-Interface Scanner with 1-D Barcode recognition
    - Top cover: tin oxide glass (EL6111)
    - Top cover: Sapphire-Glass (EL6131)
  • Multi-Interface Scanner with 1-D/2-D Barcode recognition
    - Top cover Sapphire-Glass (EL6132)
  • Additional interface cable alternatives
    - RS232 Interface cable with Power of Terminal (POT) connection cable (EL4607-2) USB interface with USBpowered 12V POT connection cable (EL-DLSE-12)
    - RS232 Interfacecable for external power supply unit (EL-DLSE-20)
    - External power supply unit (EL-DLSEP-1)
    - Power lead EU (EL-DLSEP-2)
  • Optional
    - EAS Interlock cable EL4304-2
    - Can be used for EL43, EL46, EL60 and EL61

INTERFACES

  • RS232
  • USB

ENVIRONMENTAL CONDITIONS

  • Via external power supply unit (EL-DLSE-20 +EL-DLSEP-1 + EL-DLSEP-2) 90–264VAC, 47–63 Hz Betrieb (max. / normal / sleep): 9,9 W / 2,8 W / 1,8 W
  • Via the powered 12V COM interface (EL-4607-2) 410mA (max.), 190mA (normal), 125mA (sleep)
  • Via the powered 12V USB interface (EL-DLSE-12) 410mA (max.), 190mA (normal), 125mA (sleep)

APPROVALS

  • CE, TÜV, KCC / Korea, VCCI / Japan, BSMI / Taiwan, NOM / Mexico, C-Tick / Australia, PCT / Russia, China RoHS, EU RoHS

BAR CODE TYPES

  • Linear 1D barcodes
    • UPC A / UPC E
    • EAN 8 / EAN 13
    • JAN 8 / JAN 13
    • GS1 Databar™ codes
    • GS1 DataBar Expanded Stacked
    • GS1 DataBar Stacked
    • GS1 DataBar Stacked Omnidirectional
    • Interleaved 2 of 5
    • Standard 2 of 5
    • Code 128 / EAN 128
    • Code 39
    • Code 93
    • Code 32 Italian Pharmacode
  • Additionally with the 2D version
    • PDF417MicroPDF417
    • DatamatrixMaxiCode
    • QR Code
    • Aztec Code

OPICAL DATA

  • Minimum resolution: 5 mils
  • Image sensor: 1280 x 1024
  • Read rate: 39 million pixels/second
  • Read height: 100 mm
  • Image capture:
    - 1280 x 1024 pixels, format *.jpg/*.bmp
  • Lighting:
    - Several LEDs 625 nm
  • Print contrast: 25%

DIMENSIONS: DEPTH x WIDTH x HEIGTH

  • 87 mm x 152 mm x 152 mm

WEIGHT

  • 790 grams

The availability of the Systems and certain features/functions displayed may vary by geography and are subject to change.
