DN Series™ BEETLE

A unified platform of all-in-one POS, modular POS and touch displays

Differentiation by Design – Modularity at its best – Optimized Serviceability – Best TCO

View Larger

BEETLE A1050

The new BEETLE A1050 is a 15“ all-in-one touch POS terminal and kiosk system with a sealed and fanless system design that sets a new bar for the industry.

View Larger

BEETLE A1150

The new BEETLE A1150 is a 15.6” all-in-one touch POS terminal and kiosk system with a sealed and fanless system design that sets a new bar for the industry.

Features & Benefits Specifications

Unified and modern product design for displays, all-in-one and modular POS systems.

Highly modular and scalable product design for flexibly configurations and easy service.

Innovative Click & Connect system design.

Made for retail with a sealed and fanless system design.

Easily upgradable to new technologies.

Modern USB-C based I/O interface concept.

The desktop management agent BEETLEINFO supports remote asset management and remote monitoring.

Investment protection through unbeatable 5-year product availability plus 7 years of spare parts and support.

Software:

Windows 10 IoT Enterprise DNLPOS (Linux)

Services Options:

Global Deployment and Implementation Services:

Installation and integration into existing environments

Maintenance Services: fast Recovery and Security Services

Managed Services: Store Lifecycle Management, Transformational Outsourcing, Consulting Services

BEETLE A1050

Height

(w/stand): 377 mm (14.85 inches)
(w/o stand): 273 mm (10.75 inches)

Width

339 mm (13.35 inches)

Depth

(w/stand): 207 mm (8.15 inches)
(w/o stand): 38 mm (1.5 inches)

Weight

(w/stand): approx. 5 kg (approx. 11 lbs)
(w/o stand): approx. 3 kg (approx. 6.6 lbs)

BEETLE A1150

Height

(w/stand): 342 mm (13.5 inches)
(w/o stand): 236 mm (9.3 inches)

Width

376 mm (14.8 inches)

Depth

(w/stand): 207 mm (8.15 inches)
(w/o stand): 40 mm (1.6 inches)

Weight

(w/stand): approx. 5 kg (approx. 11 lbs)
(w/o stand): approx. 3 kg (approx. 6.6 lbs)

BEETLE A1050 BEETLE A1150
Type 15” LED-backlit LCD (4:3) 15.6” LED-backlit LCD (16:9)
Resolution 1024 x 768 Full HD 1920 x 1080
Intel Processor Celeron 4305UE /2x 2.0 GHz

Core i3-8145UE /2x 2.2-3.9 GHz

Core i5-8365UE /4x 1.6-4.1 GHz
Celeron 4305UE /2x 2.0 GHz

Core i3-8145UE /2x 2.2-3.9 GHz

Core i5-8365UE /4x 1.6-4.1 GHz
Main memory 4 GB – 16 GB DDR4 RAM 4 GB – 16 GB DDR4 RAM
Dimensions in mm (WxDxH) 339 x 207 x 377 376 x 207 x 342
Product Card  BEETLE A1050 Product Card  BEETLE A1150 Product Card
The availability of the Systems and certain features/functions displayed may vary by geography and are subject to change.
