Print stations

• 1 (receipt)

Printing Method

• Thermal direct (203 dpi)

Printing columns (max.)

• 44 standard
• 56 compressed

Printing speed

• 200 mm/s monochrome

Character density

• 16.9 cpi standard
• 20.3 cpi compressed

Paper width

• 80 mm +0 / - 0.5 mm
• 57.5 mm + / - 0.5 mm (option)

Paper roll diameter

• Max. 83 mm

Sensors

• Paper low
• Paper end
• Cover open

Power supply

• 24 V DC

Receipt cutter

• Partial cut and full cut
• Reliability 2.5 million cuts

Codepages

• 437, 720, 737, 775, 850, 852, 857, 858, 860, 862, 863, 864, 865, 866, 874, 1250, 1251, 1252, 1254, 1255, 1256, 1257, 28591, 28592, 28594, 28596, 28599, 28605
• Separate model for Asian Character support

Barcodes

• UPC-A
• UPC-E
• JAN8 (EAN8)
• JAN13 (EAN13)
• CODE 39
• CODE 93
• CODE 128
• ITF
• CODABAR
• PDF417
• QR
• GS
• Data Matrix

Ambient temperature (operation)

• 0°C to 50°C, 20% to 90%RH (40°C)

Ambient temperature (storage)

• -40°C to 60°C, 20% to 93%RH (40°C)

Interfaces USB

• RS232c & USB-B

INTERFACE FOR CASH DRAWERS ON THE PRINTER

• RJ12

Other features

• Buzzer
• • Adapter for 57.5 mm paper (option)
• Vertical operating

Software support

• Windows 32/64bit Driver
• ProBase POS
  - JavaPOS
  - OPOS-UDM
• CUPS (Linux)

Dimensions (W x H x D in mm)

• 200mm×145mm×145mm

Weight

• Approx. 1.45 kg

Colors

• Black
• Light gray
